iq_2026-10-08T08:47:39Z_2Msps_cs16_hsgr_cut200.raw detected

File	Partial observations/iq_2026-10-08T08:47:39Z_2Msps_cs16_hsgr_cut200.raw
Station	hsgr-athens
Start (UTC)	2026-10-08T08:50:59Z (override)
Sample rate	2 Msps (filename)
Centre frequency	401.500000 MHz
Format	cs16 (filename)
Size	400 MB (50 s)
Analysed	2026-10-11T17:54:34Z in 7 min
Overrides	`{"start": "2026-10-08T08:50:59Z"}`

Results per code and code repetitions

Branch	Result	Max GLRT	Threshold	Above / total	Doppler track	Data
gold0_cr10	detected	273.3728	103.0115	794 / 2442	08:51:34.084Z – 08:51:37.831Z, 178 windows, Doppler +2443 → +2443 Hz	.dat
gold0_cr20	detected	478.6784	146.6204	511 / 1221	08:51:23.891Z – 08:51:38.097Z, 328 windows, Doppler +3420 → +2443 Hz	.dat
gold0_cr40	detected	851.8035	229.5378	285 / 610	08:51:19.059Z – 08:51:43.377Z, 276 windows, Doppler +3908 → +1466 Hz	.dat
gold1_cr10	detected	117.2351	87.8702	86 / 2442	08:51:08.968Z – 08:51:09.581Z, 23 windows, Doppler -2931 → -4397 Hz	.dat
gold1_cr20	detected	192.6082	131.2228	47 / 1221	08:51:08.252Z – 08:51:09.848Z, 31 windows, Doppler -2931 → -3908 Hz	.dat
gold1_cr40	detected	294.0508	198.875	26 / 610	08:51:08.169Z – 08:51:09.890Z, 17 windows, Doppler -3420 → -3420 Hz	.dat

Interactive plots

Loading the estimations…

Top: the GLRT of every estimation divided by the threshold of its branch, so that all branches share one scale (1 = threshold). Bottom: the Doppler offset of the estimations at or above the chosen multiple of the threshold. Drag to zoom (the panels share the time axis), double-click to reset, click a legend entry to hide it; the camera icons export PNG or SVG. Colour is the code, shade and marker the code repetitions.

Waterfall

Static images (6 PNG, one per branch)

gold0_cr10

gold0_cr20

gold0_cr40

gold1_cr10

gold1_cr20

gold1_cr40

Re-run

Files

result.json · job.json · flowgraph.log
